Introduction
CAMC 6×4 tipper truck is suitable for short and medium distance transport in construction and mining projects.It possesses reliable structure, strong load capacity, strong power, stable performance, high cost performance and high market awareness. This dump truck can adapt to harsh environments of construction site and mining area. CAMC is the sole brand to be treated as the model of heavy-duty industry twice. Our tipper trucks can satisfy different demands of users both home and abroad.
Features
1.6×4 dump truck features compact structure, elegant appearance and wide field of vision. It is also very comfortable and spacious.
2.Matched with Dongfeng Cummins engine, this tipper truck enjoys the advantages of strong carrying capacity, strong power, high reliability, strong climbing ability and high speed.
3.Our 6×4 dump trucks are designed with high safety, which guarantees good protection of drivers and passengers.
4.With high efficient and oil-saving strong driving force, CAMC 6×4 tipper truck is simple and comfortable to operate.
Technical Specifications of CAMC 6×4Tipper Truck
| Product Name | Dump Truck | |
| Product Model | HN3250P34C2M3 | |
| Place of Origin | Maanshan, Anhui, China | |
| Kerb Mass | 12.3 ton | |
| Rated Payload | 20-40 ton | |
| Drive Type | Left-Hand (Optional RHD) | |
| Drive Model | 6 × 4 | |
| Vehicle Body Color | Yellow (Optional) | |
| Overall Dimension (L × W × H) mm | 7840 × 2495 × 3240 | |
| Body Interior (mm) | 5200 × 2300 × 1200 | |
| Engine | Brand | DONGFENG CUMMINS |
| Model | L340 30 | |
| Max. Power (kw/r/min) | 250/2200 | |
| Max. Torque (N. m/r/min) | 1350/1400 | |
| No. of Cylinder | 6 | |
| Bore × Stroke (mm) | 114 × 145 | |
| Displacement | 8900 ml | |
| Control Type | Mechanical | |
| Air Cleaner | Dry Paper Element | |
| Emission Standard | Euro II | |
| Clutch | Type | Hydraulic Control with Air Assisted |
| Plate Diameter | Dry Single Plate with Diaphragm Outside Diameter: 430 mm | |
| Transmission | Brand | FAST GEAR |
| Model | RT-11509C (9-speed & 1-reverse) | |
| Type | Mechanical | |
| The Number of Axles | 3 | |
| Rear Axle (Drive Axle)-Load | 16000 kg × 2 | |
| Front Axle-Load | 7500 kg | |
| Cabin Type | Classic Flat-Roof (Optional EF, CH, EH) | |
| Cabin | With A/C, Radio, MP3, Bunk | |
| Brake System | Service | Full Air Brake Dual Circuit |
| Parking | Spring Actuator at Rear Wheels | |
| Auxiliary | Exhaust Break | |
| Steering System | Recirculation Ball with Integral Power Assisted by Oil | |
| Wheelbase (mm) | 3200+1350 | |
| Wheel/Tire | Type | Bias/Radial Tube/Radial Tubeless |
| Model (Optional) | 11.00-20/11.00R20/11R22.5 12.00-20/12.00R20/12R22.5 | |
| Tire Number | 10+1 | |
| Fuel Tank | Volume (L) | 320 |
| Body Steel Thickness | Bottom: 8 mm; Side: 5 mm | |
| Body Lifting System | Hydraulic Central Lift | |
| Front Overhang/Rear Overhang (mm) | 1370/1560 | |
| Approach/Departure Angle (°) | 24/25 | |
| No. of Steel Spring (Front/Rear) | 9/12 | |
| Max. Speed (km/h) | 75 | |
With the annual production capacity of 100,000 sets, CAMC has already formed the high-end 4×2 tipper truck represented by Xingkaima, the middle and high-end series products represented by CAMC heavy dump truck and the middle-end series products represented by CAMC Star. Established in 2003, Auhui Hualing Automobile Co., Ltd is a leading supplier of CAMC heavy duty trucks in China. In addition, we also supply heavy tractor truck, cargo truck, mixer truck, special vehicle chassis and heavy axle for sale. With decades of production and sale experience, our tipper trucks are exported to more than 60 nations and regions, such as Eastern Europe, North Africa, the Middle East, Central Asia, Southeast Asia, South America, etc.
