Lightweight Principle of CMAC Heavy-duty Truck Tractor 4×2:
With excellent the performance, bearing capacity and security of truck, the lightweight treatment is realized by optimizing the design structure, applying new materials and technologies and adopting the lightweight assembly.
Main Technical Performance and Specification of CAMC Heavy Truck Tractor
| Weight Reduction Item | State before Weight Reduction | Optimizing Structure Design | New Material Application | Weight Reduction |
| Frame | 8+5mm layer frame | Optimized to be 10mm single-layer frame | Adopt WL650 high-strength single-layer frame plate | 110KG |
| Spring | Front 4/rear 9+6 | Front 4/rear 9+6 | 6KG |
| Product Model | Axle Base(mm) | Driven Type | Allowable Dragging Mass | Total Mass (kg) | Engine | Max Power | Spring Leaf | Tire Specification | Transmission Box | Drive Axle |
| HN4180HP34C4M3 | 3400 | 4×2 | 34005 | 18000 | P11C-UJ | 350 | 4/9+6 | 11.00R20 12.00R20 12.00R22.5 |
12JS160TA | HL460 |
| HN4180HP34C4M3 | 3400 | 4×2 | 34005 | 18000 | ISMe345 | 345 | 4/9+6 | 11.00R20 12.00R20 12.00R22.5 |
12JS160TA | HL460 |
| HN4180HP34C4M3 | 3400 | 4×2 | 34005 | 18000 | WP10.336N | 336 | 4/9+6 | 11.00R20 12.00R20 12.00R22.5 |
12JS160TA | HL460 |
| HN4180HP34C4M3 | 3400 | 4×2 | 34005 | 18000 | ISLe340 | 340 | 4/9+6 | 11.00R20 12.00R20 12.00R22.5 |
12JS160TA | HL460 |
| HN4180HP34C4M3 | 3400 | 4×2 | 34005 | 18000 | WD615.95E | 336 | 4/9+6 | 11.00R20 12.00R20 12.00R22.5 |
12JS160TA | HL460 |
| HN4180HP34C4M3 | 3400 | 4×2 | 34005 | 18000 | L34030 | 340 | 4/9+6 | 11.00R20 12.00R20 12.00R22.5 |
12JS160TA | HL460 |
