| Relevant Dimensions(mm) | Motive Power of Tractor Truck 6×4 | ||
| Model | tractor 6 × 4 | Engine model | SC9DT320Q3 |
| Axle base | 3900+1350 | Pattern | Orthostichous, six-cylinder |
| Overall length | 7460 | Electric cabinet mixing, spark plug ignition | |
| Overall width | 2495 | Rated output/speed(kw/r/min) | 235/2200 |
| Overall height | 2965/3560/3800 | Max torque/speed(Nm/r/min) | 1250/1400 |
| Container length | ______ | Cylinder diameter × stroke(mm) | 114×144 |
| Container width | ______ | Air inlet method | supercharge inter-cooling |
| Container height | ______ | Displacement(L) | 8.82 |
| Overall front suspension | 1370 | Idling speed | 650±25 |
| Overall rear suspension | 840 | Cooling method | Water cooling |
| ground clearance from saddle | 1400 | Max net power/speed | 233/2200 |
| Frame height | 314 | Fuel | NG |
| Frame width | 940/850 | Noise | <93 |
| Front/rear track base | 2065/1860 | Discharge | Euro-3 |
| Weight Parameters(kg) | Steering System of CNG,LNG Tractor Truck 6×4 | Clutch System of 6×4 Tractor Truck | |||
| Overall mass | 9405 | Diverter | ø100 | Pattern | ø430 Clutch |
| Chassis kerb mass | ______ | Steering kinetic pump | Liquid pump | Control system | Hydraulic pneumatic control |
| Loading mass (announcement) | 37000 | ||||
| Overall weight (announcement) | 25000 | ||||
| Transmission Performance | Brake System of Tractor | Other Parameters | |||
| Top speed(km/h) | 120 km/h | Pattern | Double-circuit pneumatic braking | Tire model | 11.00R20 |
| Max grade ability | 30% | Brake type | Drum-type braking | Air tank volume | 1120M³ |
| Gearbox model | 9JS119 | Parking braking | Spring-type | Battery capacity | 135 Ah |
| Gearbox gears | 9 | Emergency braking | Spring-type | ||
| Speed ratio of drive axle | 4.44 | ||||
