Introduction
CAMC 6×4-1 tractor head is one of our hot selling products. It adopts advanced key assemblies and it is reasonably connected by advanced technology. This truck tractor enjoys outstanding performances on power, economical efficiency, reliability and environmental protection. It owns the advantages of reliable structure, strong load capability, superior power and stable performance. This tractor head is well suited for highway long-distance transportation and high-speed highway transportation. In addition to 6×4 truck tractor, our company also supplies 4×2 model. Clients can choose the suitable trailer head truck according to specific transportation requirements.
Features
1.Its cab is beautiful, elegant, safe and comfortable.
2.6×4-1 tractor head features compact structure, elegant line, wide vision, large door opening angle and large cab tilting angle.
3.This truck tractor possesses the advantages of light weight, high load capacity, strong power, strong climbing ability and high speed.
4.This tractor head is easy and convenient to maintain.
Technical Parameters of 6×4 Truck Tractor
| Product Name | Tractor Truck | |
| Product Model | HN4250G37CLM3 | |
| Place of Origin | Maanshan, Anhui, China | |
| Kerb mass | 8.8 ton | |
| Rated Payload | 100 ton | |
| Drive Type | Left-Hand (Optional RHD) | |
| Drive Model | 6 × 4 | |
| Vehicle Body Color | Yellow (Optional) | |
| Overall Dimension (L × W × H) mm | 6750 × 2495 × 3300 | |
| Engine | Brand | DONGFENG CUMMINS |
| Model | L375 30 | |
| Max. Power (kw/r/min) | 276/2200 | |
| Max. Torque (N. m/r/min) | 1480/1400 | |
| No. of Cylinder | 6 | |
| Bore × Stroke (mm) | 114 × 145 | |
| Displacement | 8900 ml | |
| Control Type | Mechanical | |
| Air Cleaner | Dry Paper Element | |
| Emission Standard | Euro II | |
| Clutch | Type | Hydraulic Control with Air Assisted |
| Plate Diameter | Dry Single Plate with Diaphragm Outside Diameter: 430 mm | |
| Transmission | Brand | FAST GEAR |
| Model | 12JS160T (12-speed & 2-reverse) | |
| Type | Mechanical | |
| The Number of Axles | 3 | |
| Rear Axle (Drive Axle)-Load | 2 × 16000 kg | |
| Front Axle-Load | 7500 kg | |
| Cabin Type | Classic Flat-Roof (Optional EF, CH, EH) | |
| Cabin | With A/C, Radio, MP3, Bunk | |
| Brake System | Service | Full Air Brake Dual Circuit |
| Parking | Spring Actuator at Rear Wheels | |
| Auxiliary | Exhaust Break | |
| Steering System | Recirculation Ball with Integral Power Assisted by Oil | |
| Wheelbase (mm) | 3,200+1350 | |
| Wheel/Tire | Type | Bias/Radial Tube/Radial Tubeless |
| Model (Optional) | 11.00-20/11.00R20/11R22.5 12.00-20/12.00R20/12R22.5 | |
| Tire Number | 10+1 | |
| Fuel Tank | Volume (L) | 380 |
| The Working Platform | With | |
| Diversion Cover | Optional | |
| Front Overhang/Rear Overhang (mm) | 1370/1020 | |
| Approach/Departure Angle (°) | 24/23 | |
| No. of Steel Spring (Front/Rear) | 9/9 | |
| Max. Speed (km/h) | 90 | |
Auhui Hualing Automobile Co., Ltd (CAMC) is a leading supplier and exporter of tractor heads in China. In addition to this truck tractor, we also supply mixer truck, cargo truck, general dump truck, mining dump truck, special vehicle chassis and overall vehicle series for engineering and municipal government, heavy axle, and so on. With decades of production and sale experience, our 6×4 tractor heads are exported to more than 60 nations and regions, such as Eastern Europe, North Africa, the Middle East, Central Asia, Southeast Asia, South America, etc. CAMC truck tractors have got good reputation both home and abroad.
