HomeProductsGas Tractor Truck CNG Tractor Truck and LNG Tractor Truck 4×2

Mixer Truck (10m3)
Tractor truck

Relevant Dimensions(mm) Motive Power of Tractor Truck 4×2
Model              Tractor 4× 2 Engine model SC9DT280Q3
Axle base 3740 Pattern Orthostichous, six-cylinder
Overall length 6130   Electric cabinet mixing, spark plug ignition
Overall width 2495 Rated output/speed(kw/r/min) 206/2200
Overall height 2965/3560 Max torque/speed(Nm/r/min) 1120/1400
Container length ______ Cylinder diameter x stroke(mm) 114×144
Container width ______ Air inlet method supercharge inter-cooling
Container height ______ Displacement(L) 8.82
Overall front suspension 1370 Idling speed 650±25
Overall rear suspension 1020 Cooling method Water cooling
ground clearance from saddle 1400 Max net power/speed 196/2200
Frame height 314 Fuel NG
Frame width 940/850 Noise <93
Front/rear track base 2065/1860 Discharge Euro-3

Weight Parameters(kg) Steering System of Tractor Truck Clutch System of CNG,LNG Tractor Truck 4×2
Overall mass 7500 Diverter ø100 Pattern ø430 Clutch
Chassis kerb mass ______ Steering kinetic pump Liquid pump Control system Hydraulic pneumatic control
Loading mass (announcement) 31505
Overall weight (announcement) 18000
Transmission Performance Brake System of 4×2 Tractor Truck Other Parameters
Top speed(km/h) 120 km/h Pattern Double-circuit pneumatic braking Tire model 11.00R20
Max grade ability 30% Brake type Drum-type braking Air tank volume 1120M³
Gearbox model 9JS119 Parking braking Spring-type Battery capacity 135 Ah
Gearbox gears 9 Emergency braking Spring-type
Speed ratio of drive axle 4.44
